英飞凌●优派克(EUPEC)
|
|
● TT 系列双可控硅模块
|
| ● TZ 系列单可控硅模块 |
|
|
● TD 、DT 系列可控硅 + 二极管混合模块 |
| ● DD 系列双二极管模块 |
| ● DZ 、 ND 系列单二极管模块 |
| ● 快速可控硅、快速二极管模块 |
| |
| ● TT 系列双可控硅模块（ SCR / SCR Phase Control ） |
|
Product Type
|
VDRM /VRRM (V)
|
ITAVM @ TC = 85°C (A)
|
Package Style(底板宽度)
|
| TT61N12-16KOF |
1200V,1400V,1600V |
60
|
PB20
|
| TT70N16-24KOF |
1600V,1800V,2000V,2200V,2400V |
70
|
PB25
|
| TT85N18-20KOF |
1800V,2000V |
85
|
PB25
|
| TT92N12-16KOF |
1200V,1400V,1600V |
92
|
PB20
|
| TT104N12-14KOF |
1200V,1400V |
104
|
PB20
|
| TT106N12-18KOF |
1200V,1400V,1600V,1800V |
106
|
PB25
|
| TT121N12-20KOF |
1200V,1400V,1600V,1800V,2000V |
121
|
PB30
|
| TT122N18-24KOF |
1800V,2000V,2200V,2400V |
122
|
PB34
|
| TT131N12-16KOF |
1200V,1400V,1600V |
131
|
PB30
|
| TT140N18-22KOF |
1800V,2000V,2200V |
140
|
PB34
|
| TT142N12-16KOF |
1200V,1400V,1600V |
142
|
PB34
|
| TT150N20-26KOF |
2000V,2200V,2400V,2600V |
150
|
PB50
|
| TT162N12-16KOF |
1200V,1400V,1600V |
162
|
PB34
|
| TT170N12-18KOF |
1200V,1400V,1600V,1800V |
170
|
PB50
|
| TT180N12-16KOF |
1200V,1400V,1600V |
180
|
PB34
|
| TT210N12-18KOF |
1200V,1400V,1600V,1800V |
210
|
PB50
|
| TT215N18-24KOF |
1800V,2000V,2200V,2400V |
215
|
PB50
|
| TT240N28-38KOF |
2800V,3000V,3200V,3400V,3600V,3800V |
240
|
PB60
|
| TT250N12-18KOF |
1200V,1400V,1600V,1800V |
250
|
PB50
|
| TT251N12-18KOF |
1200V,1400V,1600V,1800V |
250
|
PB50
|
| TT285N12-16KOF |
1200V,1400V,1600V |
285
|
PB50
|
| TT310N20-26KOF |
2000V,2200V,2400V,2600V |
310
|
PB60
|
| TT330N12-16KOF |
1200V,1400V,1600V |
330
|
PB50
|
| TT375N18-22KOF |
1800V,2000V,2200V |
375
|
PB60
|
| TT380N10-18KOF |
1000V,1200V,1400V,1600V, 1800 |
380
|
PB60
|
| TT400N20-26KOF |
2000V,2200V,2400V,2600V |
400
|
PB60
|
| TT425N10-18KOF |
1000V,1200V,1400V,1600V, 1800 |
425
|
PB60
|
| TT430N18-24KOF |
1800V,2000V,2200V,2400V |
430
|
PB60
|
| TT500N12-18KOF |
1200V,1400V,1600V,1800V |
500
|
PB60
|
| TT570N10-16KOF |
1000V,1200V,1400V,1600V |
570
|
PB60
|
|
Product Type
|
VDRM /VRRM (V)
|
ITAVM @ TC = 85°C (A)
|
Package Style(底板宽度)
|
| TZ150N20-26KOF |
2000V,2200V,2400V,2600V |
150
|
PB50
|
| TZ240N28-36KOF |
2800V,3000V,3200V,3400V,3600V |
240
|
PB50
|
| TZ310N20-26KOF |
2000V,2200V,2400V,2600V |
310
|
PB50
|
| TZ375N18-22KOF |
1800V,2000V,2200V |
375
|
PB50
|
| TZ400N20-26KOF |
2000V,2200V,2400V,2600V |
400
|
PB50
|
| TZ425N12-18KOF |
1200V,1400V,1600V,1800V |
425
|
PB50
|
| TZ430N18-24KOF |
1800V,2000V,2200V,2400V |
430
|
PB50
|
| TZ500N12-18KOF |
1200V,1400V,1600V,1800V |
500
|
PB50
|
| TZ530N30-36KOF |
3000V,3200V,3400V,3600V |
530
|
PB70
|
| TZ600N12-16KOF |
1200V,1400V,1600V |
600
|
PB50
|
| TZ630N22-28KOF |
2200V,2400V,2600V,2800V |
630
|
PB70
|
| TZ740N18-22KOF |
1800V,2000V,2200V |
740
|
PB70
|
| TZ800N12-18KOF |
1200V,1400V,1600V,1800V |
800
|
PB70
|
| |
| ● TD 系列可控硅 + 二极管混合模块( SCR / Diode Phase Control ) |
|
Product Type
|
VDRM /VRRM (V)
|
ITAVM @ TC = 85°C (A)
|
Package Style(底板宽度)
|
| TD61N12-16KOF |
1200V,1400V,1600V |
60
|
PB20
|
| TD70N16-24KOF |
1600V,1800V,2000V,2200V,2400V |
70
|
PB25
|
| TD85N18-20KOF |
1800V,2000V |
85
|
PB25
|
| TD92N12-16KOF |
1200V,1400V,1600V |
92
|
PB20
|
| TD104N12-14KOF |
1200V,1400V |
104
|
PB20
|
| TD106N12-18KOF |
1200V,1400V,1600V,1800V |
106
|
PB25
|
| TD122N18-24KOF |
1800V,2000V,2200V,2400V |
122
|
PB34
|
| TD131N12-16KOF |
1200V,1400V,1600V |
131
|
PB30
|
| TD140N18-22KOF |
1800V,2000V,2200V |
140
|
PB34
|
| TD142N12-16KOF |
1200V,1400V,1600V |
142
|
PB34
|
| TD150N20-26KOF |
2000V,2200V,2400V,2600V |
150
|
PB50
|
| TD162N12-16KOF |
1200V,1400V,1600V |
162
|
PB34
|
| TD170N12-18KOF |
1200V,1400V,1600V,1800V |
170
|
PB50
|
| TD180N12-16KOF |
1200V,1400V,1600V |
180
|
PB34
|
| TD210N12-18KOF |
1200V,1400V,1600V,1800V |
210
|
PB50
|
| TD215N18-24KOF |
1800V,2000V,2200V,2400V |
215
|
PB50
|
| TD250N12-18KOF |
1200V,1400V,1600V,1800V |
250
|
PB50
|
| TD251N12-18KOF |
1200V,1400V,1600V,1800V |
250
|
PB50
|
| TD285N12-16KOF |
1200V,1400V,1600V |
285
|
PB50
|
| TD310N20-26KOF |
2000V,2200V,2400V ,2600V |
310
|
PB60
|
| TD330N12-16KOF |
1200V,1400V,1600V |
330
|
PB50
|
| TD375N18-22KOF |
1800V,2000V,2200V |
375
|
PB60
|
| TD400N20-26KOF |
2000V,2200V,2400V ,2600V |
400
|
PB60
|
| TD425N10-18KOF |
1000,1200V,1400V,1600V,1800V |
425
|
PB60
|
| TD430N18-24KOF |
1800V,2000V,2200V,2400V |
430
|
PB60
|
| TD500N12-18KOF |
1200V,1400V,1600V,1800V |
500
|
PB60
|
| TD570N12-18KOF |
1200V,1400V,1600V,1800V |
570
|
PB60
|
| |
| ● DT 系列二极管 + 可控硅混合模块( Diode / SCR Phase Control ) |
|
Product Type
|
VDRM /VRRM (V)
|
ITAVM @ TC = 85°C (A)
|
Package Style(底板宽度)
|
| DT61N12-16KOF |
1200V,1400V,1600V |
60
|
PB20
|
| DT85N18-20KOF |
1800V,2000V |
85
|
PB25
|
| DT92N12-16KOF |
1200V,1400V,1600V |
92
|
PB20
|
| DT104N12-14KOF |
1200V,1400V |
104
|
PB20
|
| DT106N12-18KOF |
1200V,1400V,1600V,1800V |
106
|
PB25
|
| DT131N12-16KOF |
1200V,1400V,1600V |
131
|
PB30
|
| DT142N12-16KOF |
1200V,1400V,1600V |
142
|
PB34
|
| DT150N20-26KOF |
2000V,2200V,2400V,2600V |
150
|
PB50
|
| DT162N12-16KOF |
1200V,1400V,1600V |
162
|
PB34
|
| DT170N12-18KOF |
1200V,1400V,1600V,1800V |
170
|
PB50
|
| DT210N12-18KOF |
1200V,1400V,1600V,1800V |
210
|
PB50
|
| DT250N12-18KOF |
1200V,1400V,1600V,1800V |
250
|
PB50
|
| DT285N12-16KOF |
1200V,1400V,1600V |
285
|
PB50
|
| DT310N20-26KOF |
2000V,2200V,2400V,2600V |
310
|
PB60
|
| DT425N10-18KOF |
1000V,1200V,1400V,1600V, 1800V |
425
|
PB50
|
| DT500N12-18KOF |
1200V,1400V,1600V,1800V |
500
|
PB60
|
| |
| ● DD 系列双二极管模块( Diode / Diode Phase Control ) |
|
Product Type
|
VRRM (V)
|
IFAVM @<, /strong> TC = 85°C (A)
|
Package Style(底板宽度)
|
| DD89N12-18K |
1200V,1400V,1600V, 1800V |
89
|
PB20
|
| DD98N20-25K |
2000V,2200V,2500V |
98
|
PB20
|
| DD104N12-18K |
1200V,1400V,1600V, 1800V |
104
|
PB20
|
| DD106N12-22K |
1200V,1400V,1600V, 1800V,2000V,2200V |
106
|
PB25
|
| DD151N12-22K |
1200V,1400V,1600V, 1800V,2000V,2200V |
151
|
PB30
|
| DD171N12-18K |
1200V,1400V,1600V, 1800V |
171
|
PB34
|
| DD175N28-34K |
2800V,3000V,3200V,3400V |
175
|
PB50
|
| DD231N20-26K |
2000V,2200V,2400V,2600V |
231
|
PB50
|
| DD260N12-18K |
1200V,1400V,1600V, 1800V |
260
|
PB50
|
| DD261N20-26K |
2000V,2200V,2400V,2600V |
261
|
PB50
|
| DD285N04-08K |
400V, 600V, 800V |
285
|
PB50
|
| DD350N12-18K |
1200V,1400V,1600V, 1800V |
350
|
PB50
|
| DD435N28-40K |
2800V,3200V,3600V,4000V |
435
|
PB60
|
| DD540N20-26K |
2000V,2200V,2400V,2600V |
540
|
PB60
|
| DD600N12-18K |
1200V,1400V,1600V, 1800V |
600
|
PB60
|
| |
| ● DZ 、 ND 系列单二极管模块( Single Diode Phase Control ) |
|
Product Type
|
VRRM (V)
|
IFAVM @ TC = 85°C (A)
|
Package Style(底板宽度)
|
| ND89N12-18K |
1200V,1400V,1600V, 1800V |
89
|
PB20
|
| ND104N12-18K |
1200V,1400V,1600V, 1800V |
104
|
PB20
|
| ND171N12-18K |
1200V,1400V,1600V, 1800V |
171
|
PB34
|
| ND260N12-18K |
1200V,1400V,1600V, 1800V |
260
|
PB50
|
| ND261N20-26K |
2000V,2200V,2400V,2600V |
261
|
PB50
|
| ND350N12-18K |
1200V,1400V,1600V, 1800V |
350
|
PB50
|
| DZ540N20-26K |
2000V,2200V,2400V,2600V |
540
|
PB60
|
| DZ600N12-18K |
1200V,1400V,1600V, 1800V |
600
|
PB50
|
| ND600N12-18K |
1200V,1400V,1600V, 1800V |
600
|
PB60
|
| DZ950N36-44K |
3600V,4000V,4400V |
950
|
PB70
|
| DZ1070N18-28K |
1800V,2000V,2200V,2400V,2600V,2800V |
1070
|
PB70
|
| |
| ● 快速可控硅、快速二极管模块( SCR / Diode Fast ) |
|
Product Type
|
VDRM /VRRM (V)
|
ITAVM @ TC = 85°C (A)
|
tq(us)
|
Package Style(底板宽度)
|
|
IFAVM @ TC = 85°C (A)
|
| TT46F08-13KFC |
800V,1000V,1100V,1200V,1300V |
45
|
C12、D15、E20、F25 |
PB20
|
| TZ335F08-13KFM |
800V,1000V,1100V,1200V,1300V |
235
|
E20、F25、G30 |
PB50
|
| DD46S08-12K |
800V,1000V, 1200V |
45
|
|
PB20
|
| DD61S10-14K |
1000V, 1200V,1400V |
61
|
|
PB20
|
| DD81S10-14K |
1000V, 1200V,1400V |
81
|
|
PB20
|
| DD82S06-10K |
600V,800V,1000V |
81
|
|
PB20
|
| DD121S10-14K |
1000V, 1200V,1400V |
121
|
|
PB30
|
| DD122S04-10K |
400V,600V,800V,1000V |
121
|
|
PB30
|
| DD230S18-26K |
1800V,2000V,2200V,2400V,2600V |
230
|
|
PB50
|
| DD241S10-14K |
1000V, 1200V,1400V |
240
|
|
PB50
|
| DD242S04-10K |
400V,600V,800V,1000V |
240
|
|
PB50
|
|
